Toyota RAV4 (XA40) 2013-2018 Service Manual: Fuel tank cap
Inspection
- Inspect fuel tank cap assembly
- Visually check that the cap and gasket are not
deformed or damaged.
If the result is not as specified, replace the cap assembly or gasket.
- Remove the gasket from the exhaust manifold.
Heated oxygen sensor
Components
Removal
Disconnect cable from negative battery
terminal
Caution:
Wait at least 90 seconds after disconnecting the
cable from the negative (-) battery terminal to
prevent ai ...
